Projection System

• DLP™

Light Source

• 210 W UHP

Light Source Life

• 5000 hours (Standard), 10000 hours (ECO)

Native Resolution

• 800 x 600

Maximum Resolution

• 1920 x 1200

Brightness

• 4000 ANSI Lumens (Standard), 3200 lm (ECO)

Aspect Ratio

• 4:3 (Native), 16:9 (Supported)

Contrast Ratio

• 20,000:1

Image Size

• 23" (58.4 cm) ~ 7.62 m (300")

Throw Ratio

• 1.96 to 2.15 (1270 mm@2000 mm)

Zoom Ratio

• 1.1x

Digital Zoom

• 2x

Lens

• F = f/2.56~f/2.68, f = 22 mm~24.10 mm, Manual Zoom, Manual Focus

Projection Mode

• Front, Rear, Ceiling, Rear Ceiling

Display Color

• 1.07 Billion Colors (30-bit)
• 1.07 Billion Colors (30-bit)

Vertical Sync Rate

• 24 ~ 120 Hz

Horizontal Sync Rate

• 15 to 100 kHz

VGA In

• x1, D-sub

VGA Out

• x1, D-sub

Video

• x1, RCA

Audio In

• x1, 3.5mm mini jack

Audio Out

• x1, 3.5mm mini jack

S/PDIF

Speaker

• x1, 3 W Speaker
• x1, 3 W Speaker

Power Consumption

• 260Watts (Standard), 205Watts (ECO)

Installation

• Ceiling Mountable

[Dimensions (W x D x H)

• 299.50 mm (11.79") x 220 mm (8.66") x 105.10 mm (4.14")
• 299.50 mm (11.79") x 220 mm (8.66") x 105.10 mm (4.14")

Weight (Approximate)

• 2.4 kg (5.3 lb)
