• Specifications

  • Product codeRB4011iGS+RM
  • ArchitectureARM 32bit
  • CPUAL21400
  • CPU core count4
  • CPU nominal frequencyauto (533 - 1900) MHz
  • CPU Threads count4
  • Switch chip modelRTL8367SB
  • Dimensions228 x 120 x 30 mm
  • RouterOS license5
  • Operating SystemRouterOS v7
  • Size of RAM1 GB
  • Storage size512 MB
  • Storage typeNAND
  • MTBFApproximately 200'000 hours at 25C
  • Tested ambient temperature-40°C to 70°C
  Powering

  • Number of DC inputs2 (DC jack, PoE-IN)
  • DC jack input Voltage12-57 V
  • Max power consumption33 W
  • Max power consumption without attachments18 W
  • PoE inPassive PoE
  • Cooling typePassive
  • PoE in input Voltage18-57 V
  PoE-out

  • PoE-out portsEther10
  • PoE outPassive PoE up to 57V
  • Low voltage PoE-Out current limit600 mA
  • High voltage PoE-Out current limit420 mA
  • Max total out (A)600 mA
  Ethernet

  • 10/100/1000 Ethernet ports10
  Fiber

  • SFP+ ports1
  Peripherals

  • Serial console portRJ45
  Other

  • PCB temperature monitorYes
  • Voltage MonitorYes
  Certification & Approvals

  • CertificationCE, EAC, ROHS
  • IPIP20
