SPECIFICATION

•  Part Number: MK5145-31A38K

•  Demension: 169mm X 63 mm X 51 mm

•  Weight: 100g Input Voltage : 5 VDC

•  Operating Power: 675 mW ( 125 Ma @5 V)

•  Host System Interfaces: USB,RS232. Keyboard Wedge, IBM 468xx (RS485)

•  Operating Temperature: 0 C to 40 C ( 32 F to 104 F)

•  Storage Temperature: -40 C to 60 C (-40 F to 140 F)

•  Humidity: 5% to 95% relative Humidity, non-condensing

•  Drop: Designed to withstand 1.5m (5)

•  Drops Environmental Sealing:​ Sealed to resist airborne particulate contaminants

•  Light Levels: 4842 Lux

•  Scan Pattern: Single Scan

•  Line Scan Speed: 72 scan lines per second

•  Scan Angle: Horizontal 50 Print

•  Contrast: 35% Minimum reflectance difference Pitch,

•  Skew: 68, 52 Decode

•  Capability: reads standard 1D and GS1 DataBar Sybologies

•  Warranty: 1 Years Factory Warranty
