Star Micronics Thermal Printer TSP143IIILAN, Gray, AutoCutter, LAN (P/N:39464910)

Star Micronics Thermal Printer TSP143IIILAN, Gray, AutoCutter, LAN (P/N:39464910)

  • Brand:Star
  • Product Code: TSP143IIILAN
  • $235.00

Printer MethodDirect Line Thermal
Print Speed43 RPM (Receipts Per Minute)
Printer Case ColorUltra White or Gray
Models AvailableAuto-Cutter with Emergency tear bar on the front guide
Print Resolution203 dpi (8 dots per mm)
Font Size12 X 24
Character SetANK 95, 32 Int 128 Graphic plus Chinese, Japanese, Korean, Taiwanese
International Code PagesStar Mode=48
Bar CodesExtended barcode functionality – 9 versions / PDF 417, Maxicode Option
Line Spacing3 mm or 4 mm or programmable
Top Margin11 mm default
Paper SpecificationsWidth: 80mm standard, 58mm with paper guide

Thickness: 0.053 ~ 0.085 mm

Roll Diameter: Up to 83 mm

Easy – Load: “Drop-In & Print”

Paper Out Sensor: Standard

Paper Low Sensor: N/A

Maximum Print Width: 80mm paper = 72mm, 58mm paper = 50.8mm

Auto CutterGuillotine (Partial Cut Only)
Cover Open SensorYes
Logo Store CapacityUnlimited
Multiple Copy SupportSupported through FuturePRNT Software
Journal CapabilitySupported through FuturePRNT Software
Label SupportN/A
Power SupplyInternal with power cable supplied
Drivers AvailableWindows 10, Windows 8.1, Windows® XP 32 Bit, Vista 32/64 Bit, Windows 7 32/64 Bit, Server 2008 32/64 Bit, XP Embedded, POSReady2009, OPOS™, JavaPOS™, USB Vendor Class, CUPS, Mac, Mac OS X, Linux™, StarPRNT SDK with support for iOS and Android
Digitally Signed (WHQL)Yes
Swappable InterfacesN/A
ConnectivityTSP100IIIWLAN (802.11b/g/n with 2.4GHz)

TSP100IIIBi – Bluetooth iOS (Apple MFi-certified)

TSP100IIILAN – Ethernet (10/100BaseT,UTP) with cable supplied


Virtual Serial Port to USB – Supported through FuturePRNT Software (TSP100, TSP100PUSB, TSP100LAN)

Virtual Serial Port to LAN – Supported through FuturePRNT Software (TSP100LAN)

Emulation ModesStar Mode

SDKs (Raster only)

Peripheral Drive Circuit2 circuits, (24V max. 1A), 1 compulsion input
Power ConsumptionAverage 1.6 Amp. Printing, 0.1 Amp. Standby
Operating ConditionsTemperature: 5oC to 45oC

Humidity: 10% – 90% RH (without condensation)

Storage ConditionsTemperature: -20oC to 60oC

Humidity: 10% – 90% RH

Dimensions142 X 132 X 204 (w x h x d)mm
WeightTSP143IIILAN – 1.73kg

TSP143IIIBi – 1.53kg

TSP143IIIW – 1.72kg

TSP143IIIU – 1.72kg

Safety StandardsUL, C-UL, TuV, FCC, VCCI, EN55022, CE
Reliability MCBF60 Million Lines

Printhead: 100km

Auto Cutter: 2 Million Cuts

Included AccessoriesWall Mount Bracket, 58mm Paper Guide, 3ft Interface Cable, 6ft Power Cable, Power Switch Cover, Easy Setup Guide, Installation CD with Drivers and FuturePRNT Receipt Design Software Auto Reverse Text Output Software (Power Cable not included with PUSB versions)
